Our Base Shoe System is a base mounted structural glass system that can be attached to the surface or the fascia that allows for continuous sightlines.
Baluster | Infill Guard | Hand Rail | Fittings | |
---|---|---|---|---|
Material | None | Glass | Stainless Steel RD Tube | Stainless Steel |
Finish | Clear, Frosted | Polished Finish | Mirror, Satin, Architectural Brush | |
Grade/Notes | Other/Specialty As Required | (#6/ 240-400G) | ||
Dimensions | 1/2″ – 27/32″ | 1.5″ X 0.120″ / 1.9″ X 0.083″ |
Mounting Options | ||
---|---|---|
Top/Surface: Mount: |
Drilled/Tapped Steel Plate/Stringer or Concrete core |
|
Side/Fascia: Mount: |
Drilled/Tapped Steel Plate/Stringer Anchored In Substrate |
